Oil Mist Filter
Durable Oil Mist Filter with Stainless Steel Housing and High Quality Imported Filter Element as Well as Robust Inlet Filter for RVP Dual Stage Industrial Rotary Vane Vacuum Pumps
Description
- Oil Mist Filter, Economic Type: MF-20 (KF25): Cost-effective quality oil mist filter with durable plastic construction
The semi-transparent half body provides added benefit of easy monitoring of oil level. It is suitable for vacuum pumps with an outlet size of KF25.
- Oil Mist Filter, Premium Type: TMS (KF25 & KF40): Durable oil mist filter with AISI 304 stainless steel housing
It includes high quality imported Italian glass fibre filter element for superior efficiency and reliability. The design with large filtering area ensures exceptional performance, effectively capturing oil mist particles with utmost effectiveness.
The version with an oil return line is designed to minimize oil loss by efficiently returning trapped vacuum oil from the oil mist filter via the gas ballast port.
- Inlet Dirt Filter: IF (KF25 & KF40): Robust inlet filter protects the vacuum pump from dirt and other particles.
Model | Size | Weight | Packing Size (CM) |
MF20 | KF25 | 65 g | 12*12*19.5 |
TMS021 | KF40 | 3.8 kg | 21*21*32 |
TMS022 | KF25 | 2.5 kg | 18*18*28 |
IF25 | KF25 | 0.4 kg | 16*15*10 |
IF40 | KF40 | 1 kg | 17*15*12 |
Click HERE to learn more about RVP Dual Stage Vacuum Pumps, Where the Oil Mist Filter and Inlet Filter are Employed.
