VP Dual Stage HVAC Vacuum Pump (Classic)
The classic VP series 2-stage HVAC air vacuum pumps feature stable performance and cost effectiveness and the quality of the pumps are proved by the market more than one decade. This line of vacuum pumps can be used with CFC, HFC, HCFC, and HFO refrigerants.
Description
The classic VP series 2-stage HVAC air vacuum pumps feature stable performance and cost effectiveness and the quality of the pumps are proved by the market more than one decade. This line of vacuum pumps can be used with CFC, HFC, HCFC, and HFO refrigerants.
Features & Benefits:
- Robust aluminum housing
- Safe operation and long service life guaranteed by thermally protected motor
- Ultimate vacuum of 15 microns or better to meet your vacuum requirements
- Oversized sight glass for easy monitoring oil quality and quantity
- Oversized 3/8″ oil drain for faster oil changes
- Low noise output
- Wide range of applications
- One year warranty
Technical Data of VP Air Vacuum Pumps:
Model | VP215 | VP225 | VP235 | VP245 | VP260 | VP280 | VP2100 |
Flow Rate (CFM) | 1.5 | 2.5 | 3.5 | 4.5 | 6 | 8 | 10 |
Ultimate Vacuum (Micron) | 25 | 25 | 25 | 25 | 25 | 25 | 25 |
Motor Power (HP) | 1/4 | 1/3 | 1/3 | 1/2 | 3/4 | 1 | 1 |
Intake Fittings | 1/4" Flare | 1/4" Flare | 1/4" Flare | 1/4" Flare | 1/4" & 3/8" Flare | 1/4" & 3/8" Flare | 1/4" & 3/8" Flare |
Power Supply | 220V/50Hz | 220V/50Hz | 220V/50Hz | 220V/50Hz | 220V/50Hz | 220V/50Hz | 220V/50Hz |
Oil Capacity (ml) | 180 | 280 | 360 | 350 | 700 | 600 | 700 |
Dimension (mm) | 270*119*216 | 278*119*216 | 320*134*232 | 320*134*232 | 370*140*250 | 370*140*250 | 370*140*250 |
N.W. (kg) | 6 | 7 | 11 | 11.8 | 15 | 15.5 | 16 |
Click HERE to learn more about all other quality refrigeration vacuum pumps and HVAC tools.
